Wave International

Wave MiniBOSS Bilge Water Filter and Monitoring System

  • IMO certified Oil Content Monitor
  • MEPC 107(49) certification
  • MED EC Type Approval
  • Only discharges bilge water within legal limits
  • High flow rate capable of 0.45m3 per hour
  • Audible and visual alarm
  • Automatic Data Logger
  • Easily replaced filters
Enquire Now

MEPC 107(49) & MARPOL Compliant Bilge Water Management

The Wavestream Wave MiniBOSS is a high-performance, IMO Certified Bilge Water Filter and Monitoring System engineered to protect our oceans while ensuring your vessel remains in total MARPOL compliance. Specifically designed for precision and reliability, the MiniBOSS prevents the discharge of oil, fuel, and microplastics, guaranteeing that all bilge water pumped overboard meets the strict legal limits of 15ppm or 5ppm.

With a focus on compact engineering and low cost of ownership, the Wave MiniBOSS is the premier choice for professional marine refits and new builds requiring world-class environmental protection.



Wave MiniBOSS Features:

  • IMO certified Oil Content Monitor (OCM) which continuously samples the filtered water audible and visual alarm to provide early warning
  • MEPC 107(49) certification; required for all vessels over 400GT
  • MED EC Type Approval
  • a high flow rate capable of 0.45m3 per hour
  • continuously samples filtered water ensuring any non conforming water is automatically returned to the bilge
  • is an integrated bulkhead mounted modular unit which is easily installed saving
    • weight – only 37.6kgs and
    • space – only 86cm x 105cm x 26cm
  • has low cost of ownership with easily replaced filters
  • has an automatic Data Logger which records for 18 months



Wave MiniBOSS Technical Specification

Specification
WMBOSS 24V
WMBOSS 110-240V
IMO MEPC Compliance Monitor 107(49) certified
Dimensions 86cms x 105cms x 26cms
Dry Weight 37.2kgs
Flow Rate 0.45 M3/hr
Filter Media Wavestream WS-C3
Test barg 3.79
Operating Pressure Up to 3.45 bar
Operating Temp Range 1 – 55 deg C
Oil Content Monitor IMO MEPC 107(49) Certified monitor
Single Phase Power Req’d 24vDC 110-120vAC or  220-240vAC
Three Phase Power Options Available only with separate transformer
Frequency 50 or 60 Hz
Max Amperage 8 amp breaker @ 24vDC 4 amp @ 110vAC 1.6 amp @220vAC
